HD series lithium battery using LiFePO4 battery cells offer the following advantages:
◆ Longer life compared to lead acid battery more than 2000 cycle life.
◆ Up to 60% weight saving
◆ 100% usable capacity (120Ah LiFePO4 approximately offers the same usable energy as a 190Ah Lead Acid battery) due to offering full voltage and current even when 80% discharged, compared to lead acid that typically only offers the required voltage at upto 50% discharged.
◆ More energy with 1/3 smaller size
◆ Less than 3% self discharging
◆ Built in safety protection
◆ Zero maintenance
◆ Easy installation
◆ Quality guaranteed
◆ Fast charging, Charge at 20Amps in under 6 hours from flat with one of our high performance chargers.
|Series & Parallel Application||max. 4 series or 4 parallel connected application|
|Recommended Charge Voltage||14.6±0.2V|
|Floating Charge Voltage||13.8±0.2V|
|Discharge Cut-off Voltage||10.0V|
|Standard Charge Current||20A|
|Max. Continuous Discharge Current||160A|
|Pulse Discharge Current (<5s)||200-400A|
|Cycle Life||>2000 cycles|
|Operation Temperature Range||Charge: 0~45℃;|
|Recommended operating temperature: 15℃~35℃|
|Self-Discharge Rate||Residual capacity: ≤3%/month; ≤15%/years|
|Reversible capacity: ≤1.5%/month; ≤8%/years|
|Storage Temperature & Humidity Range||Less than 1 month: -20℃~35℃, 45%RH~75%RH|
|Less than 3 months: -10℃~35℃, 45%RH~75%RH|
|Recommended storage environment: 15℃~35℃，45%RH~75%RH|
CE marked tested to EU Council Directive 2014/30/EU Electromagnetic Compatibility
Test std. EN 61000-6-3: 2007+A1: 2011 EN 61000-6-1: 2007.
Life Cycle according to state of discharge
