12V 60AH LiFePO4 Lithium Battery
Items | Parameter |
Battery Type | LiFePO4 |
Nominal Voltage | 12.8V |
Nominal Capacity | 60Ah |
Energy | 0.768KWh |
Internal Resistance | ≤20mΩ |
Series & Parallel Application | up to 4 series 4 parallel connected application |
Recommended Charge Voltage | 14.6±0.2V |
Floating Charge Voltage | 13.8±0.2V |
Charge Method | CC/CV |
Discharge Cut-off Voltage | 10.0V |
Standard Charge Current | 10A |
Max. Continuous Discharge Current | 60A |
Pulse Discharge Current (<5s) | 100A<5S |
Cycle Life | > 2000 cycle warranty. |
Dimension | Length: 197±2mm |
Width: 165±2mm | |
Height: 170±2mm | |
Weight | 7.5±0.2Kg |
Operation Temperature Range | Charge: 0~45℃; |
Discharge: -20~60℃ | |
Recommended operating temperature: 15℃~35℃ | |
Self-Discharge Rate | Residual capacity: ≤3%/month; ≤15%/years |
Reversible capacity: ≤1.5%/month; ≤8%/years | |
Storage Temperature & Humidity Range | Less than 1 month: -20℃~35℃, 45%RH~75%RH |
Less than 3 months: -10℃~35℃, 45%RH~75%RH | |
Recommended storage environment: 15℃~35℃,45%RH~75%RH |
